Name: PAM8610 Digital Stereo Class-D Amplifier Board 2x15W Output - Rytronics.in
Brand: Amplifiers and Sound Cards
SKU: RY-AMP8610
Price: 119.00 INR
Availability: InStock
Rating: 4.20 (5 reviews)

The power supply voltage limit is 16.5V, do not use more than this voltage. The power supply is recommended for 12v, 3A power supply filter better. 4-8 inch stereo speakers recommended. Do not short-circuit the audio output to each other or shorted to ground. Carefully check before electricity, ensure the wiring is correct before electricity.

PAM8610 Digital Stereo Class-D Amplifier Board 2x15W Output

Rated 4.20 out of 5 based on 5 customer ratings

(5 customer reviews)

₹119.00 (inc. GST)

In stock

The power supply voltage limit is 16.5V, do not use more than this voltage.
The power supply is recommended for 12v, 3A power supply filter better.
4-8 inch stereo speakers recommended.
Do not short-circuit the audio output to each other or shorted to ground.
Carefully check before electricity, ensure the wiring is correct before electricity.

SKU: RY-AMP8610 Categories: Amplifiers and Sound Cards, Audio and Video

Description

The PAM8610 is a 15W (per channel) stereo Class-D audio amplifier with DC Volume Control which offers low THD+N (0.1%), low EMI, and good PSRR thus high-quality sound reproduction. The 32 steps DC volume control has a +32dB to -75dB range. The PAM 8610 runs on a 7V to 15V supply at a much higher efficiency than competitors’ ICs.

The PAM8610 amplifier only requires very few external components, significantly saving cost and board space. This 2x15W Two-Channel Stereo Class-D Amplifier is available in a 40 pin QFN 6 x 6 mm package.

How to use:

The power supply voltage limit is 16.5V, do not use more than this voltage.
The power supply is recommended for 12v, 3A power supply filter better.
4-8 inch stereo speakers recommended.
Do not short-circuit the audio output to each other or shorted to ground.
Carefully check before electricity, ensure the wiring is correct before electricity.

Features :

This plate with a switching function, SW short, will turn off the power amplifier.
Working Mode: Class D (PWM modulation type).

Package Includes :

1 x PAM8610 Digital Stereo Class-D Amplifier Board 2x15W Output
