Name: LM741 UA741 Operational Amplifiers Op-Amp IC Integrated Circuit - Rytronics.in
Brand: IC's and Base
SKU: RY-LM741DIP
Price: 14.00 INR
Availability: InStock

Overload Protection on the Input and Output amplifiers which feature improved performance over • No Latch-Up When the Common-Mode Range is industry standards like the LM709.

LM741 UA741 Operational Amplifiers Op-Amp IC Integrated Circuit

₹14.00 (inc. GST)

In stock

Overload Protection on the Input and Output amplifiers which feature improved performance over

• No Latch-Up When the Common-Mode Range is industry standards like the LM709.

SKU: RY-LM741DIP Category: IC's and Base

Description

The 741 series are a general-purpose operational amplifier that features improved performance over industry standards like LM709. They are direct, Exceeded plug-in replacements for the 709C, LM201, MC1439, and 748 in most applications. The amplifiers offer many features which make their application nearly foolproof: overload protection on the input and output, no latch-up when the common-mode range is exceeded, as well as freedom from oscillations. The LM741C is identical to the LM741 and LM741A except that the LM741C has their performance ensured over a 0°C to +70°C temperature range, instead of −55°C to +125°C.

Features:-

• Overload Protection on the Input and Output amplifiers which feature improved performance over

• No Latch-Up When the Common-Mode Range is industry standards like the LM709.

Specification:-

Supply Voltage:	±18V
Differential Input Voltage	±15V
CMRR	90db
Differential voltage amplification	200V/mv
Supply Current	1.5mA

Package Includes:

1 x LM741 PDIP-8 Operational Amplifier IC
