KA2284 Voltage Level Indicator Module
₹149.00 (inc. GST)
In stock
Quantity based pricing
Quantity | Discount (%) | Price |
---|---|---|
1 - 5 | — | ₹149.00 |
6 - 10 | 2.68 % | ₹145.00 |
11 - 50 | 6.04 % | ₹140.00 |
51+ | 9.4 % | ₹135.00 |
- Chip: KA2284
- This Audio Level Indicator can be adjusted and easy to use
- AC and DC signals can be controlled by jumpers
- Designed with small size, lightweight, and easy to use
- It is equipped with LED indicator light, more convenient to use
- Provides Stable and Safety Performance.
Description
The KA2284 Voltage Level Indicator Module provides a logarithmic visual indication of a static or dynamic voltage level using LEDs.
The module can be used to indicate a voltage level such as for monitoring a DC battery level or for use with AC signals to implement a VU meter for audio strength or similar applications.
The module uses the KA2284 LED Dot Level Meter Driver IC to implement a logarithmic LED dot indicator display. The display consists of 5 LEDs – 3 green, 1 yellow and 1 red which are lit in sequence as the input voltage increases.
A single-turn potentiometer is used to set the range for the display.
The input for the voltage measurement includes a series capacitor for use with AC waveforms. There is a small jumper on the board which shorts this capacitor so that the module can be used with a DC signal such as when monitoring battery.
- Jumper OFF = Monitor AC voltage
- Jumper ON = Monitor DC voltage
The module can be powered off a wide voltage range of 3.5 to 16V
KEY FEATURES OF KA2284 VOLTAGE LEVEL INDICATOR MODULE:
- Uses KA2284 5-Dot LED Level Meter Driver w/ built-in rectifying amplifier
- Adjustable voltage range with LED display
- Use with AC or DC voltages
- 3.5 to 16V operation
Module Connections
There is a 4-pin header on the assembly for making connections.
1 x 4 Header
- VCC = Connect to 3.5 to 16V
- IN = Input. The voltage to be measured by the device
- GND = Ground. There are 2 ground pins, but only one needs to be used
- GND = Ground. There are 2 ground pins, but only one needs to be used
OUR EVALUATION RESULTS:
These modules work as advertised and can be useful for monitoring some types of voltages and are a very inexpensive way to experiment with VU meter type applications.
PACKAGE INCLUDES:
- KA2284 Voltage Level Indicator Module
