Name: DHT22 Digital Temperature and Humidity Sensor - Rytronics.in
Brand: Sensor and Modules
SKU: RY1259
Price: 149.00 INR
Availability: InStock
Rating: 5.00 (1 reviews)

Previous Product

DHT22 Digital Temperature and Humidity Sensor

Rated 5.00 out of 5 based on 1 customer rating

(1 customer review)

₹149.00 (inc. GST)

In stock

Operating Voltage: 3.5V to 5.5V
Operating current: 0.3mA (measuring) 60uA (standby)
Output: Serial data
Temperature Range: -40°C to 80°C
Humidity Range: 0% to 100%
Resolution: Temperature and Humidity both are 16-bit
Accuracy: ±0.5°C and ±1%

SKU: RY1259 Categories: Sensor and Modules, Sensors, Temp, Humidity & Gas Sensor

Description

Product Description

The DHT22 Digital Temperature and Humidity Sensor is a basic, low-cost digital temperature and humidity sensor. It uses a capacitive humidity sensor and a thermistor to measure the surrounding air and spits out a digital signal on the data pin (no analog input pins needed).

Its fairly simple to use, but requires careful timing to grab data. The only real downside of this sensor is you can only get new data from it once every 2 seconds, so when using our library, sensor readings can be up to 2 seconds old.

Simply connect the first pin on the left to 3-5V power, the second pin to your data input pin and the rightmost pin to ground. Although it uses a single-wire to send data it is not Dallas One Wire compatible! If you want multiple sensors, each one must have its own data pin!

Features

Relative humidity and temperature measurement
Calibrated digital signal
Outstanding long-term stability
Extra components not needed
Long transmission distance
Low power consumption
4 pins packaged and fully interchangeable

Applications

Measure temperature and humidity
Local Weather station
Automatic climate control
Environment monitoring

Package Includes

1 x DHT22 Digital Temperature and Humidity Sensor

1 review for DHT22 Digital Temperature and Humidity Sensor

Rated 5 out of 5

prabudh (verified owner) – 11/07/2024

Cheapest In India

Only logged in customers who have purchased this product may leave a review.
