2S 5A 8.4V 18650 Lithium Battery Charger Board Protection Module

109.00 (inc. GST)

In stock

  • Cash on Delivery(COD) available on orders above 499/-
  • Free shipping on prepaid orders above 499/- use FREESHIP Coupon code!
  • 10 Days Return Policy!
  • Dispatch in 24 Hours from Warehouse!
Add to Wishlist
Add to Wishlist
  1. Input Voltage: 8.4 –  9V.
  2. Overcharge Detection Voltage: 4.25-4.35V±0.05V.
  3. Over-Discharge Detection Voltage: 2.3-3.0V±0.05V.
  4. Maximum Working Current: 5A.
  5. Transient Current: 7A.

Description

2S 5A 8.4V 18650 Lithium Battery Charger Board Protection Module has the main IC using original “precision” imported components. With overcharge, over-discharge, over current, short circuit protection function, for a variety of different shapes of 3.7V capacity lithium batteries. Using the Japanese precision protection IC, VISHAY, AOS, IR, and other high-quality MOSFET, an FR-4 low-temperature coefficient of the plate, well-designed, comprehensive test. Compact size, suitable for many requirements of high integration, low-cost occasions, can meet the performance requirements of many aspects, to ensure the absolute safety of the battery group.

Protections :

  1. Short circuit protection.
  2. Overcharge protection.
  3. Over-discharge protection.
  4. Over-current protection.

Connections :

MB: The Common connection point between the batteries.

B+: Battery V+ Positive.
B-: Battery V- Negative.
P+: Charging V+.
P-: Charging V-.

Specifications :

  1. Maximum Working Current: 5A.
  2. Transient Current: 7A..
  3. Operating Temperature: -40-50℃.
  4. Internal Resistance: Less than 45m Ω.
  5. B+ B-: The interface of battery core.
  6. P+ P-: The connector of the battery board.

Package Includes :

1 x 2S 5A 8.4V 18650 Lithium Battery Charger Board Protection Module.
